EVH Wolfgang MIJ Series - Edward Van Halen Signature - Ebony Fingerboard - Stealth - Made in Japan

Exclusively from our team of talented craftsmen in Japan, EVH® brings you the MIJ EVH Signature Wolfgang® model, which comes loaded with Eddie Van Halen’s preferred touring specs and the behemoth and versatile sound expected from an instrument bearing his name.

The basswood body features a big leaf maple top and five-ply binding, while the bolt-on quartersawn maple neck is sculpted to Eddie’s precise specs, with graphite reinforcement for the ultimate protection against climate-induced warping, hand-rubbed satin urethane back finish for smooth, fast playability and a heel-mount truss rod spoke wheel for quicker neck adjustments when needed.

Designed to enhance playing comfort from chords to leads to bends, the 12"-16" compound radius ebony fingerboard has 22 vintage stainless-steel frets.

Experience monstrous, perfectly-balanced tone with dynamic pick attack via a custom-wound alnico 2 EVH® Wolfgang® humbucker in the bridge and an alnico 3 custom-wound EVH Wolfgang humbucker in the neck, both controlled by a special reverse oriented three-way toggle switch. The bridge pickup delivers the perfect amount of punch and articulation with sweet sustain and thick chunky rhythms, while the neck pickup serves up quintessential creamy neck tones and endless sustain along with articulate cleans when the volume is rolled down.

A custom-designed EVH BI Tech HPU low friction volume knob creates even-volume tapering for the smoothest volume swells, while the EVH Bourns® high friction tone knob will stay in place even if accidentally bumped. A lower bout kill switch mutes the guitar for those popular stutter, rhythmic effects.

Equipped with a “dive-bomb” certified EVH-branded top-mount Floyd Rose® bridge, the locking tailpiece features fine tuners for each string and a patented EVH D-Tuna® for switching back and forth from drop-D to standard tuning in an instant.

The all-new MIJ Series EVH Signature Wolfgang® is offered in Ivory or Stealth Black finishes, each with cream body binding, black knurled control knobs, chrome eye hook strap buttons and black headstocks. The Ivory finish features pearloid block inlays and chrome nut, retainer bar and tuners, while the Stealth finish features pearloid dot inlays, chrome nut, black retainer bar and black tuners.

An EVH Wolfgang hardshell case, EVH leather strap and dog leash strap/eye-bolt brass clasps are included.

Corpo

• CORPO - Basswood
• FINITURA CORPO - Satin Urethane
• FORMA CORPO - Wolfgang®
• TOP DEL CORPO - Big Leaf Maple
• BINDING DEL CORPO - 5-Ply
• MATERIALE DEL CORPO - Basswood

Manico

• PALETTA - EVH® Wolfgang®
• MATERIALE DEL MANICO - Quartersawn Maple
• FINITURA MANICO - Hand-Rubbed Satin Urethane
• FORMA DEL MANICO - Wolfgang® Backshape
• COSTRUZIONE MANICO - Bolt-On with Graphite Reinforcement
• SPESSORE MANICO - .805" at 3rd & .890" at 12th Fret
• RAGGIO TASTIERA - 12"-16" Compound Radius (304.8 mm to 406.4 mm)
• MATERIALE TASTIERA - Ebony
• SEGNATASTIPear - l Dot
• SEGNAPOSIZIONE LATERALI - Perla
• NUMERO DI TASTI - 22
• DADO DEL TRUSS ROD - Heel-Mount Truss Rod Adjustment Wheel
• CAPOTASTO - Floyd Rose® R2 Locking
• LARGHEZZA CAPOTASTO - 1.650" (42 mm)
• MATERIALE DEL CAPOTASTO - Floyd Rose® R2 Locking

Hardware

• PONTE - EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®
• BLOCCO DEL VIBRATO - Brass
• PICKUP COVERS - Zebra
• MANOPOLE DI CONTROLLO - Black Knurled with White Indicator
• PUNTA LEVETTA SELETTORE - Black
• FINITURA HARDWARE - Chrome
• STRUMENTI PER L’ACCORDATURA - EVH®-Branded Gotoh®
• ALBERELLI ABBASSACORDE - Floyd Rose® Retainer Bar
• CORDE - EVH® Nickel Plated Steel (.009-.042 Gauges)
• LEVA DEL VIBRATO - Floyd Rose® 1000 Series Locking
• REGGICINGHIA - Screw-Eye Hook

Elettroniche

• PICKUP AL PONTE - Direct Mount EVH® Wolfgang® Humbucking
• PICKUP AL MANICO - Direct Mount EVH® Wolfgang® AL3 Humbucking
• CONFIGURAZIONE DEL PICKUP - HH
• CONTROLLI - Volume (EVH® BI Tech HPU Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH® Bourns® High Friction Pot)
• SWITCHING - EVH® Reverse-Style 3-Position Switching: Position 1: Neck Pickup, Position 2: Neck and Bridge, Position 3: Bridge
• SELEZIONE AUX - Kill Switch

Accessories

• ACCESSORI INCLUSI - Tremolo Arm, Hex Keys & User Manual
• CHIAVE PER TRUSS ROD - 2.5 mm Hex
